TP-Link TL-SF1008P 8-Ports 10/100Mbps Desktop Switch With 4-Port PoE

Buy TP-Link TL-SF1008P 8-Ports 10/100Mbps Desktop Switch With 4-Port PoE online at Rs. 11990. Buy complete range of Desktop Switches on Vmart.pk, We Offer home delivery all over Pakistan.

• With four PoE ports, transfers data and power on one single cable
• Working with IEEE 802.3af compliant PDs, expands home and office network
• Requires no configuration and installation

TL-SF1008P is an 8 10/100Mbps ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to ­fix devices such as APs, IP Cameras or IP Phones, etc.

4 of the 8 Auto-Negotiation RJ45 ports (port-1 to port-4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).

TL-SF1008P has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 57W, a priority will be arranged among the PoE ports, then the system will cut o‑ the power of the lowest-priority port.

Priority (port-1=port-2=port-3>port-4): This function will help to ensure the normal operation of the system, it means Port 4 will be cut off when all total PoE PDs power consumption exceed 57W. For an example, Port 1, 2 and 4 is using 15.4W (maximum power for per port is 15.4W); the system power is 46.2W in total. If there is an additional PD inserted to Port 3 with 12W, and then the system will cut off the power of Port 4 because of the overloaded power, this means Port 1, 2 will use 15.4W, and Port3 will use 12W, no power will be supplied to Port 4.

8 10/100Mbps RJ45 Ports, AUTO Negotiation/AUTO MDI/MDIX

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

100BASE-TX: UTP category 5, 5e cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

No

60.2W (220V/50Hz)

3.2W (220V/50Hz)

External Power Adapter(Output: 48VDC / 1.25A)

(RJ45) Standard: 802.3 af compliant

Port1- Port4

57W

1.6Gbps

Table 2K

6.7*3.9*1.1 in. (171*98*27 mm)

2.66(220/50Hz. no PD connected), 65.92(220/50Hz. with 57W PD connected)

9.08BTU/h(no PD connected), 224.92BTU/h(with 57W PD connected)

Store-And-Forward\

Compatible With

IEEE 802.3af Compliant PDs

Priority Function

Mac Address Auto-Learning And Auto-Aging

IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode

FCC, CE, RoHS

TL-SF1008P, Power Adapter, User Guide

2.3 watts (max. no PD connected)

59.3 watts (max. with 57w PD connected)

0℃~40℃ (32℉~104℉)

-40℃~70℃ (-40℉~158℉)

10%~90% non-condensing

5%~90% non-condensing
