TP-Link RE590T AC1900 Touch Screen Wi-Fi Range Extender

Features

AC1900 Touch Screen Wi-Fi Range Extender
RE590T

Touch to extend like never before.
Connections you can rely on.

The RE590T is designed to make Wi-Fi range extension as simple and efficient as possible. Extend your Wi-Fi with streamlined setup procedures on a touchscreen interface that is as easy to use as your smartphone. The 4.3-inch capacitive touchscreen provides an intuitive, interactive window into your extended network that revolutionizes your Wi-Fi experience. The RE590T - Born to extend with the power of touch.

Simple, reliable setup.
Completely at your fingertips.

Why waste time with an unreliable WPS connection or a complicated web UI? The RE590T provides simple, step-by-step instructions on the integrated screen, freeing you from the frustration and confusion of network configuration. Simply select the Wi-Fi networks and bands (2.4GHz and/or 5GHz) that you wish to extend and confirm the network name and password to expand your wireless coverage with a 100% success rate.

A clear window into network management.
An elegant blend of beauty and utility.

The integrated touchscreen and intuitive user interface provide direct access to the range extender’s management features, eliminating the need for additional devices. Interacting with the RE590T’s network settings is as easy as using your smartphone. Device control options, wireless settings, and signal strength information can all be found on the responsive touchscreen. For added convenience, the touchscreen can display a beautifully designed clock that makes the RE590T an elegant and functional addition to your home’s decor.

Extend Wi-Fi for your whole home.
Up to 10,000* square feet of additional coverage.

Three dual band antennas with 700mW high-powered amplifiers allow the RE590T to extend up to 10,000* square feet of additional Wi-Fi coverage. The 1GHz dual core Broadcom processor further broadens the reach of wireless signal and ensures excellent performance, allowing you to experience stable connections no matter where you are in your home.

Beamforming Technology

Advanced Beamforming technology allows the range extender to locate wireless devices and concentrate its wireless signal strength towards them to form stronger, more reliable connections.

*Maximum extended Wi-Fi coverage specifications are based on performance test results. Actual Wi-Fi coverage may vary due to environmental factors and external sources of wireless interference.

Truly impressive wireless and wired speed.
Ideal for 4K streaming and online gaming.

Stream Ultra HD video without buffering, play online games without lag, and download large files in a flash. Blazing fast AC Wi-Fi speeds of up to 1900Mbp and 4 Gigabit Ethernet ports provide optimal performance for multiple devices, ensuring that everyone on your network can enjoy smooth streaming video and low-latency online gaming.

2.4GHz 600Mbps Wi-Fi
5GHz 1300Mbps Wi-Fi

Experience Redefined - From the Inside Out
AC1900 Touch Screen Range Extender


Specifications

HARDWARE FEATURES

Interface

4*10/100/1000Mbps Ethernet Ports(RJ45)

Button Reset Button, Power On/Off Button

Antenna 3 dual band detachable antennas

External Power Supply 12V/2.5A

Dimensions ( W x D x H ) 11.2 x 6.2 x 2.1 in. (284 x 157 x 52 mm)

Touch Screen Screen Type: Capacitive

Screen Size: 4.3 inch

Screen Resolution: 128 ppi

WIRELESS FEATURES

Wireless Standards IEEE 802.11a/ac, IEEE 802.11b/g/n

Frequency 2.4GHz & 5GHz(11ac)

Signal Rate Up to 1300Mbps @5GHz, Up to 600Mbps @2.4GHz

Reception Sensitivity

2.4GHz:
11g 54M: -76dBm@10% PER
11n HT20 MCS7: -73dBm@10% PER
11n HT40 MCS7: -71dBm@10% PER

5GHz:
11a 6Mbps:-94dBm@10% PER
11a 54Mbps: -75dBm@10% PER
11ac HT20 MCS8: -66dBm@10% PER
11ac HT40 MCS9: -62dBm@10% PER
11ac HT80 MCS9: -59dBm@10% PER

Wireless Modes Range Extender

Wireless Functions Concurrent Mode boost both 2.4G/5G Wi-Fi band, Devices Control, Domain Login Function

Wireless Security 64/128-bit WEP, WPA-PSK / WPA2-PSK

Transmission Power CE: <20dBm(2.4GHz), <23dBm(5GHz), FCC: <30dBm

OTHERS

Certification CE, FCC, RoHS

System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 8.1,10, Mac® OS, NetWare®, UNIX® or Linux.

Environment

Operating Temperature: 0?~40? (32? ~104?)
Storage Temperature: -30?~70? (-22? ~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
