TP-Link M7300 LTE-Advanced Mobile Wi-Fi

LTE-Advanced Mobile Wi-Fi
M7300


• Share 4G connection with up to 150Mbps download/50Mbps upload speeds
• Supports up to 11 devices simultaneously (10 Wireless+1 Wired)
• 2000mAh battery for 10 hours of usage
• High speed Wi-Fi hotspot at speeds of 300Mbps
• Equipped with a Micro SD card slot for up to 32GB of optional storage
• Easy management with the tpMiFi App

Wi-Fi Goes Where You Go

Do more with a Faster Connection

The M7300 supports the latest generation 4G LTE networks, providing convenient carry-on Wi-Fi that can reach speeds of up to 150Mbps. Now you can enjoy lag-free HD video, fast file downloads, and stable video chats regardless of where life takes.

Share with friends
Internet access for up to 11 devices Simultaneously

This compact device works seamlessly with an impressive range of wireless gadgets. The M7300 can easily share a 4G/3G connection with up to 10 wireless devices like tablets, laptops, and mobile phones at the same time. It can also provide internet access for desktop computers via the integrated USB port.

Get Your Network Up
and Running in Seconds

M7300 features a compact and user-friendly design, all you need is to insert a SIM card and press the power button. Your high-speed 4G hotspot will be operational within a half minute.

Easy Management
with the tpMiFi App

With the tpMiFi App, you can easily access and manage the M7300 from your connected iOS/Android devices. The tpMiFi app allows you to establish data limits, control which devices can access your Wi-Fi, send messages, and share media files to/from a removable Micro SD card.

Micro SD Card Wireless Sharing

The integrated Micro SD card slot allows you to easily share photos, music, videos and more wirelessly across your network from a inserted micro SD card
– supports optional storage of up to 32G*.

* Micro SD card sold separately.
* You can access and share files using tpMiFi App for iOS/Android.

Specifications

HARDWARE FEATURES

Interface 1 micro USB port for power supply
1 SIM card slot
1 Micro SD card slot

Button Power On/Off

Power Supply Internal 2000mAh Rechargeable Battery

Antenna Internal Antenna

Network Type (M7300 v1)

4G: FDD-LTE B1/B3/B7/B8/B20 (2100/1800/2600/900/800MHz)

3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900MHz)

2G: EDGE/GPRS/GSM Quad Band (850/900/1800/1900MHz)

Network Type (M7300 v2 with TDD-LTE)

4G: FDD-LTE B1/B3/B7/B8/B20 (2100/1800/2600/900/800MHz)

TDD-LTE B38/B40/B41 (2300/2500/2600MHz)

3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900MHz)

2G: EDGE/GPRS/GSM Quad Band (850/900/1800/1900MHz)

Data Rates DL: 150Mbps, UL: 50Mbps

Dimensions ( W x D x H ) 4.0×2.5×0.6 in. (102.6×63×16mm)

Micro SD Card Reader Up to 32GB

LED Display Wi-Fi status, Internet connection status, Battery status

OTHERS

Certification CE, FCC, RoHS, IPX5

System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7,
MAC OS, NetWare, UNIX or Linux.

Note: We recommend you to use one of following Web browsers for an improved user
experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.

Environment Operating Temperature: -40°C~70°C (-40℉~158℉)

Storage Temperature: -40℃~70℃ (-40℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~95% non-condensing
