TP-Link Archer CR700 AC1750 Wireless Dual Band DOCSIS 3.0 Cable Modem Router

AC1750 Wireless Dual Band DOCSIS 3.0 Cable Modem Router

Archer CR700

• Supports 802.11ac standard - the next generation of Wi-Fi
• Simultaneous 2.4GHz 450Mbps and 5GHz 1300Mbps connections provide a ultra-wireless experience
• 680Mbps DOCSIS 3.0 Cable Modem provides 16X faster download speed than DOCSIS 2.0 for an ultra-fast performance
• Beamforming technology delivers a more targeted and highly efficient wireless connection
• Dual-core processor ensures no interruption when simultaneously processing multiple wireless or wired tasks
• Dual USB ports – Access files & media from networked devices or remotely via FTP server and share a printer locally
• Certified for XFINITY® from Comcast®, Time Warner Cable®, Cablevision and Bright House Networks.

Features

Enjoy the Best Networking Experience by Upgrading to the Latest Modem and Router Technology

Your current and future smart devices can perform to their full potential by taking advantage of the newest standards in modem router technology. Utilizing the latest DOCSIS 3.0 modem protocol and 802.11ac wireless technology ensures both cable download speeds of up to 680Mbps and gigabit Wi-Fi speeds. The result is lag-free online gaming and seamless music and HD video streaming.

Greater Convenience and Flexibility

Free up space by combining your cable modem and Wi-Fi router into a single compact, elegantly designed device.

Protect the Network

Parental and Access Control features from the web management page grant you the ability to safeguard your network, restricting who can join and what content users may access while on it.

Easy, Efficient Data Access

Two USB ports make storing, accessing, and sharing data hassle-free by allowing multiple USB devices to connect to the modem router at the same time without the need for a separate USB hub.

• FTP Server
• Storage Sharing
• Video Server
• Photo Server
• Printer Sharing
• Music Server

You can access USB devices connected to the modem router through your network or remotely using FTP technology. This allows you to download or stream media from flash and hard drives, including music, photos, and movies, as well as share printers across your network.

Keep Everyone Connected

With the number of Wi-Fi-enabled devices found in the home growing steadily, a network that can stretch its coverage to every room and reliably connect to several devices at once has become a necessity. The CR700 creates a strong Wi-Fi network throughout the home—upstairs, downstairs, and even outside. High powered amplifiers boost its wireless signal, a speedy processor handles bandwidth-intensive tasks, and its large amount of memory helps minimize lag and data buffering losses. The modem router is also equipped with beamforming technology, which increases its range by allowing it to focus independent signals towards devices rather than simply broadcasting in all directions.

Specifications

HARDWARE FEATURES

Memory

16 MB flash and 256MB RAM

Interfaces

4 10/100/1000Mbps RJ45 LAN Ports 1 Coax Port 2 USB 2.0 Ports

Button

1 Power On/Off Button 1 WPS Button 1 Wi-Fi On/Off Button 1 RESET Button

Dimensions (W X D X H)

9.0 x 6.3 x 1.5 in. (229 x 160 x 37mm)

External Power Supply

12VDC/3.5A

IEEE Standards

IEEE 802.3, 802.3u, 802.3ab

DOC SIS Standards

DOCSIS® 1.0, 1.1, 2.0, & 3.0

Antenna Type

6 internal antennas

Radio Amplifiers

High-powered radio amplifiers

WIRELESS FEATURES

Wireless Standards

IEEE 802.11ac/n/a 5GHz IEEE 802.11n/g/b 2.4GHz

Wireless Speeds

2.4GHz: Up to 450Mbps 5GHz: Up to 1300Mbps

Frequency

2.4GHz and 5GHz

Transmit Power

<20dBm(EIRP)

Wireless Functions

Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics

Wireless Security

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryption, Wireless MAC Filtering

Wireless Schedule

Support 2.4GHz and 5GHz Wireless Schedule

SOFTWARE FEATURES

Security

NAT Firewall, Access Control

IPv6

IPv6 and IPv4 dual stack

Management

Web Based Configuration(HTTP), Remote management, SSL for TR-069, SNMP v1/2c, Diagnostic Tools

DHCP

Server, Client, DHCP Client List

Port Forwarding

Virtual server, Port Triggering, DMZ, ALG, UPnP

Dynamic DNS

DynDns, NO-IP

VPN Pass-Through

PPTP, L2TP, IPSec Passthrough

Advanced Functions

Parental Control, MAC/IP/URL Filtering, Network Address Translation (NAT); RIP v1/v2 (optional); DNS Relay, DDNS, IGMP V1/V2/V3

USB Sharing

Support Samba(Storage)/FTP Server/Media Server/Printer Server

Guest Network

2.4GHz guest network × 1 5GHz guest network × 1

OTHERS

System Requirements

Windows 8/7/Vista/XP or Mac OS or Linux-based operating system

Environment

Operating Temperature:

0?~40? (32?~104?)

Storage Temperature:

-40?~70? (-40?~158?)

Operating Humidity:

10%~90% non-condensing

Storage Humidity:

5%~90% non-condensing
