Super Fast Transfer Speeds Providing a Superior Wi-Fi Experience
Archer C8 comes with the next generation 11ac Wi-Fi standard, offering total data transfer speeds achieving up to 1.75Gbps, with 1.3Gbps over the clearer 5GHz channel, and 450Mbps over the 2.4GHz Channel. Ultra-fast 800MHz dual-core CPU function as a great ‘heart’ for fast, stable and responsive performance with Wi-Fi, Ethernet and USB devices. Whole home coverage with excellent Gigabit Wi-Fi are ideal for bandwidth intensive applications such as HD video streaming and online gaming, allowing you to enjoy a super-fast connected home.
Greater Coverage and Reliable Wi-Fi
Archer C8’s 3 dual band antennas with high powered signal amplifiers guarantee continuous Wi-Fi speeds to all your devices while boosting Wi-Fi coverage throughout your home.
Beamforming Technology for Efficient Wi-Fi
Archer C8's beamforming technology locate your connected devices and boost wireless signal strength in those directions, delivering a more targeted and highly efficient wireless connection.
Dual USB Ports for Easy Sharing
With one ultrafast USB 3.0 port and one USB 2.0 port, you can easily access and share a printer locally and files & media with networked devices or remotely via the router’s FTP server. The USB 3.0 port provides up to 10x faster USB hard drive access than legacy USB 2.0 connections.
Gigabit Wired Connections for Ultrafast Data Transfer Speeds
Full shielded Gigabit WAN-LAN ports can achieve blazing WAN to LAN throughput of up to 1000Mbps. Archer C8 is a powerful hub to support a robust and extremely fast wired network.
Modern and Elegant Appearance
Archer C8’s novel shape catches people’s eyes with its beauty, decorating a modern home. With numerous ventilation holes in the back, uninterrupted high speed performance is guaranteed. With gentle curves, excellent crafting and remarkable quality, its design exudes fashion and elegance.
Features
Specifications
HARDWARE FEATURES | |
---|---|
Interface | 4 10/100/1000Mbps LAN Ports 1 10/100/1000Mbps WAN Port 1 USB 3.0 Port + 1 USB 2.0 port |
Button | WPS/Reset Button Wireless On/Off Switch Power On/Off Button |
External Power Supply | 12V/3.3A |
Dimensions (W X D X H) | 8.7 X 3.4 X 6.6 in. (221 X 86 X 168.5mm) |
Antenna | 3 dual band detachable antennas |
WIRELESS FEATURES | |
---|---|
Frequency | 2.4GHz and 5GHz |
Wireless Standards | IEEE 802.11ac/n/a 5GHz IEEE 802.11b/g/n 2.4GHz |
Signal Rate | 5GHz: Up to 1300Mbps 2.4GHz: Up to 450Mbps |
Reception Sensitivity | 5GHz? 11a 6Mbps-96dBm 11a 54Mbps: -79dBm 11ac HT20: -71dBm 11ac HT40: -66dBm 11ac HT80: -63dBm 2.4GHz 11g 54M: -77dBm 11n HT20: -74dBm 11n HT40: -72dBm |
Transmit Power | CE: <20dBm(2.4GHz) <23dBm(5GHz) FCC: <30dBm |
Wireless Functions | Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
Wireless Security | 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption |
SOFTWARE FEATURES | |
---|---|
WAN Type | Dynamic IP/Static IP/PPPoE/ PPTP(Dual Access)/L2TP(Dual Access)/BigPond |
DHCP | Server, Client, DHCP Client List, Address Reservation |
Quality of Service | WMM, Bandwidth Control |
Port Forwarding | Virtual Server, Port Triggering, UPnP, DMZ |
Dynamic DNS | DynDns, Comexe, NO-IP |
VPN Pass-Through | PPTP, L2TP, IPSec |
Access Control | Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
Firewall Security | DoS, SPI Firewall IP Address Filter/MAC Address Filter/Domain Filter IP and MAC Address Binding |
Protocols | Supports IPv4 and IPv6 |
USB Sharing | Support Samba(Storage)/FTP Server/Media Server/Printer Server |
Management | Access Control Local Management Remote Management |
Guest Network | 2.4GHz guest network × 1 5GHz guest network × 1 |
OTHERS | |
---|---|
Certification | CE, FCC, RoHS |
Package Contents | AC1750 Wireless Dual Band Gigabit Router Archer C8 3 detachable antennas Power supply unit Resource CD Ethernet Cable Quick Installation Guide |
System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, Windows 8, MAC OS, NetWare, UNIX or Linux |
Environment | Operating Temperature: 0?~40 ? (32 ?~104?) Storage Temperature: -40?~70 ? (-40 ?~158?) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Warranty
18 months local warranty
