TP-Link Archer C58 AC1350 Wireless Dual Band Router

The Advanced 802.11ac Wi-Fi gets your home network revolutionized

Concurrent 2.4GHz 450Mbps and 5GHz 867Mbps dual band Wi-Fi connections

Three high gain external antennas provide strong Wi-Fi signals

Support advanced functions like Parental Control and Guest Network

Tether app ensures an easy router management in your palm

The Archer C58 comes with the brand new Wi-Fi standard – 802.11ac, widely compatible with both wireless AC and wireless N devices and three times faster than previous wireless N speeds. With this cutting edge technology, the Archer C58 offers you faster, stronger and more capable Wi-Fi. Simply put: a revolutionized network experience on all your devices.

The Archer C58 provides your entire home with simultaneous dual band Wi-Fi connections. The strong and stable 2.4GHz wireless band with 450Mbps Wi-Fi speed is perfect for sending emails, browsing the web or listening to music. Meanwhile, the 5GHz wireless band provides up to 867Mbps Wi-Fi speed for latency-sensitive entertainment so you can stream HD video, play online games and hold video chats all at the same time, without delay.

The Archer C58’s three high performance external antennas ensure full home Wi-Fi coverage. Combined with a dual band wireless network, its increased stability and range means you will no longer suffer from weak, dropped connections.

Supervise children and staff with responsible access, controlled by parents or administrators. Use URL blocking to easily set up a black or white list and limit the level of web access.

Allow guests to join your Wi-Fi network, while protecting your privacy. Make sharing easy, maintain security.

Set up the Archer C58 in minutes thanks to its intuitive web interface. Configuration is also in the palm of your hands with TP-LINK’s powerful app, Tether, the easiest way to access and manage your router through your smartphone.

Interface 4 10/100Mbps LAN Ports

1 10/100Mbps WAN Port

Button WPS/Reset Button

Wireless On/Off Switch

Power On/Off Button

Antenna Three 5dBi external antennas

External Power Supply 12VDC/1A

Dimensions ( W x D x H ) 8.9 × 5.8 × 1.3 in. (225×148×33 mm)

Wireless Standards IEEE 802.11ac/n/a 5GHz

IEEE 802.11b/g/n 2.4GHz

Wireless Speeds 450Mbps(2.4GHz)

867Mbps(5GHz)

Frequency 2.4-2.5GHz

5.15-5.25GHz

Transmit Power 13.5dBm Max(2.4GHz)

17dBm Max(5GHz)

Wireless Modes Wireless Router

WDS(Four Address)

WDS(AP+APC)

Wireless Security WEP

WPAWPA2

WPA-PSKWPA2-PSK

Wireless MAC Filter

SOFTWARE FEATURES

Quality of Service WMM, Bandwidth Control

WAN Type Dynamic IP/Static IP/PPPoE/

BigPond/ /L2TP(Dual Access) /PPTP(Dual Access)

Management Access Control

Local Management

Remote Management

DHCP DHCP Server

DHCP Client

DHCP Client

Address Reservatio

VPN Pass-Through PPTP

L2TP

IPSec(AH Head)

IPSec(ESP Head)

Access Control Parental Control

Local Management Control

Host List

Access Schedule

Rule Management

Protocols IPv4

IPv6

Guest Network 2.4GHz guest network

5GHz guest network

Certification CE, RoHS

Package Contents AC1350 Wireless Dual Band Router Archer C58

Power supply unit

Ethernet Cable

Quick Installation Guide

Environment Operating Temperature: 0℃~40 ℃ (32 ℉~104℉)

Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

Operating System Microsoft Windows XP/Vista/7/8/8.1/10

MAC OS, NetWare, UNIX or Linux
