TP-Link Archer AC2300 Wireless MU-MIMO Gigabit Router

TP-Link AC2300 Wireless MU-MIMO Gigabit Router

With NitroQAM Technology, Archer C2300 boosts the Wi-Fi Speed up to 1625Mbps on 5GHz and 600Mbps on 2.4GHz. It can perfectly handle your favorite activities like gaming online, watching 4K movies, or sharing large files.

With XStream processor architecture, the Archer C2300 dedicates one processor to each of its Wi-Fi bands. These processors handle Wi-Fi traffic, freeing the router’s powerful 1.8 GHz dual-core 64-bit CPU to take care of everything else.

MU-MIMO lets the Archer C2300 talk to several devices at once, and Smart Connect automatically places each device on the best available Wi-Fi band. With both working together, everyone can hop online at the same time without having to wait, and each device can always get the best connection.

RangeBoost amplifies the router's ability to detect and receive Wi-Fi signal from devices that are located farther away. Stream, game and enjoy what you love anywhere in your home, from your favorite spot on the couch to the comfort of your bed.

USB 3.0 and 2.0 ports make it easy to share photos, videos, and music on your home network.

When away from home, a VPN allows you to securely access NAS drives and other devices connected to the router through USB.

Archer C2300 is not only supporting safe and secure OpenVPN and PPTP VPN connection, but also using VPN Acceleration to boost the connection speed. All of the data you're transmitting is guaranteed to be secured by these VPN functions.

Setup and manage your Wi-Fi through the free TP-Link Tether app, available for both Android and iOS. Tether’s simple layout lets you quickly access all of your Wi-Fi settings on your phone or tablet.

• Watch 4K movies and game with high-speed AC2300 dual-band Wi-Fi
• Powerful 1.8GHz dual-core 64-bit CPU with two co-processors deliver smooth and speedy connections
• RangeBoost greatly improves Wi-Fi connection to devices located farther away
• MU-MIMO connects more Wi-Fi devices at once for faster performance
• Airtime Fairness equally divides attention between newer and older devices to improve Wi-Fi performance
• TP-Link HomeCareTM protects against the latest threats with powerful security and antivirus
• Best for Simultaneous
• 4K Streaming and Gaming

512MB RAM and 128MB Flash

4 10/100/1000Mbps LAN Ports,

1 10/100/1000Mbps WAN Port

1 USB 3.0 Port + 1 USB 2.0 Port

Wi-Fi On/Off Button, Reset Button, WPS Button, Power On/Off Button, LED on/off Button

3 Detachable Antennas

12V/2A

8.5 x 6.5 x 1.4 in.(216 x 164 x 36.8 mm)

IEEE 802.11ac/n/a 5GHz

IEEE 802.11b/g/n 2.4GHz

2.4GHz and 5GHz

1625Mbps at 5GHz, 600Mbps at 2.4GHz

11a 6Mbps: -91dBm

11a 54Mbps: -72dBm

11n HT20: -70dBm

11n HT40: -69dBm

11ac HT20: -60dBm

11ac HT40: -61dBm

11ac HT80: -56dBm

2.4GHz: 11g 54Mbps: -73dBm

11n HT20: -72dBm

11n HT40: -69dBm

Wireless Functions Enable/Disable Wireless Radio, WMM,

Wireless Statistics

Wireless Security

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions

<20dBm(2.4GHz), <23dBm(5GHz)

<30dBm

2.4GHz guest network x 1, 5GHz guest network x 1

Quality of Service WMM, Bandwidth Control

WAN Type Dynamic IP/Static IP/PPPoE/

PPTP(Dual Access)/L2TP(Dual Access) /Bigpond

Management Access Control, Local Management, Remote Management

DHCP Server, Client, DHCP Client List, Address Reservation

Port Forwarding Virtual Server, Port Triggering, UPnP, DMZ

Dynamic DNS TP-Link DynDns, NO-IP

VPN Pass-Through PPTP, L2TP

Access Control Parental Control, Local Management Control,

Host list, Access Schedule, Rule Management

Protocols Supports IPv4 and IPv6

Advanced Features Smart Connect, Airtime Fairness, Link Aggregation

USB Sharing Support Samba(Storage)/FTP Server/Media Server/

Printer Server

VPN Server PPTP, OpenVPN

Certification CE, FCC, RoHS

Package Contents AC2300 Wireless MU-MIMO Gigabit Router

Archer C2300

3 Detachable Antennas

Power Supply Unit

Ethernet Cable

Quick Installation Guide

Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux

Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled Brower

Subscription with an Internet Service Provider (for Internet access)

: 0℃~40℃ (32℉ ~104℉)

: -40℃~70℃ (-40℉ ~158℉)

: 10%~90% non-condensing

: 5%~90% non-condensing
