- The world’s first SideClick EasySwap design for 3.5” HDD
- Built-in latest USB 3.0 SuperSpeed connector
- Supports up to 7 additional fans for optimized air flow
- Convenient drive installation with 90o rotated cage
- Top and front blue LED fan for the ultimate combat ambience
Cooling System
HDD Air Cooling System
1. Front (intake): CPU Air Cooling System 2. Top (exhaust): VGA Air Cooling System |
Unique Design
SideClick EasySwap for 3.5" HDD |
Built-in latest USB3.0 SuperSpeed connector |
Specifications
Model | VM20001W2Z |
Case Type | Middle Tower |
Dimension (H x W x D) | 480.0 x 210.0 x 500.0 mm (18.9 x 8.3 x 19.7 inch) |
Side Panel | Transparent Window |
Color | Exterior & Interior: Black |
Material | SECC |
Cooling System | Front (Intake) : 120 x 120 x 25 mm Blue LED fan, 1000rpm, 16dBA; 120 x 120 x 25 mm (optional) or 200 x 200 x 20 mm (optional) Rear (Exhaust) : 120 x 120 x 25 mm TurboFan, 1000rpm, 16dBA Top (Exhaust) : 200 x 200 x 20 mm Blue LED fan, 800rpm, 15dBA; Two 120 x 120 x 25 mm (optional) Bottom (Intake) : 120 x 120 x 25 mm (optional) Side (Intake) : 120 x 120 x 25 mm (optional) |
Drive Bays | - Accessible : 5.25” x 3, 3.5” x 1 - Hidden : SideClick EasySwap 3.5” x 1, 3.5’’ & 2.5” x 5 |
Expansion Slots | 7 |
Motherboards | Micro ATX , Standard ATX |
I/O Ports | USB3.0 x 1, USB2.0 x 1, eSATA connector x 1, MIC & Speaker (support AC’97 & HD Audio) |
PSU | Standard ATX PS2 (optional) |
Net Weight | 7.1 kg / 15.7 lb |
Other | CPU cooler height limitation: 180mm Graphic card length limitation: 305mm |
Warranty : 1 Year Company Provided
