Kingston 1TB SSDNow KC400 SATA3 2.5 7mm

SSDNow KC400 Drive

Kingston's KC400 SSD is 15 times faster than a hard drive to deliver consistent performance for both compressible and incompressible data and improve responsiveness in performance-hungry applications. It uses a Phison PS3110-S10 8-channel controller and quad-core processor to speed up daily tasks and improve productivity.

KC400 provides end-to-end data path protection and SmartECC to guard data, plus SmartRefresh to protect against read errors. Data is rebuilt if there's an error, and the drive is able to recover from an unexpected power shutdown, thanks to firmware-controlled power loss management. Advances in controller technology and NAND give this drive excellent data reliability.

KC400 is backed by a limited five-year warranty an

d legendary Kingston support, including technical teams ready to help you select the right solid-state drive for your needs, and global, industry-leading post-sales support plus Kingston's Ask an Expert programme. To monitor and manage your drive, there's the Kingston SSD Manager, a free, downloadable application available on the Kingston website.

To suit your needs, KC400 is available in 128GB, 256GB, 512GB and 1TB capacities.

Features

• 15 times faster than a hard drive
• Business-class reliability with advanced data protection
• Legendary pre- and post-sales support
• Available in a range of full capacities

Specifications

Form factor: 2.5"

Interface:
SATA Rev. 3.0 (6Gb/s) – with backwards compatibility to SATA Rev. 2.0 (3Gb/s)

Capacities: 128GB, 256GB, 512GB, 1TB

Controller: Phison 3110

Sequential Read/Write: SATA Rev. 3.0:

128GB – up to: 550/450MB/s
256GB – up to: 550/540MB/s
512GB – up to: 550/530MB/s
1TB – up to: 550/530MB/s

Maximum 4k Read/Write:
128GB – up to 99,000/87,000 IOPS
256GB – up to 99,000/88,000 IOPS
512GB – up to 99,000/86,000 IOPS
1TB – up to 99,000/89,000 IOPS

Random 4k Read/Write:
128GB – up to 88,000/87,000 IOPS
256GB – up to 88,000/89,000 IOPS
512GB – up to 86,000/88,000 IOPS
1TB – up to 86,000/89,000 IOPS

PCMARK® Vantage HDD Suite Score: 84,000

Enterprise S.M.A.R.T. Tools reliability tracking, usage statistics, life remaining, wear leveling, temperature

Total Bytes Written (TBW) :
128GB: 150TB 0.65 DWPD5
256GB: 300TB 0.65 DWPD5
512GB: 800TB 0.87 DWPD5
1TB: 1600TB 0.89 DWPD5

Power Consumption:
0.255 W Idle / 0.335 W Avg / 1.22 W (MAX) Read / 3.74 W (MAX)

Storage temperatures: -40°C ~ 85°C

Operating temperatures: 0°C ~ 70°C

Dimensions: 69.9mm x 100.1mm x 7.0mm

Weight:

60g

Vibration operating: 2.17G Peak (7–800Hz)

Vibration non-operating: 20G Peak (10–2000Hz)

MTBF: 1 million hours
