HP Color LaserJet Pro MFP M177fw

Printer specifications

Functions

Print, copy, scan, fax

Print speed, black (normal)

Up to 17 ppm

Print speed, color (normal)

Up to 4 ppm

Print speed

Measured using ISO/IEC 24734, excludes first set of test documents. For more information see hp.com/products1/ISO/MMDPP/index.html. Exact speed varies depending on the system configuration, software application, driver, and document complexity.

Printer page yield

Introductory cartridges included; yields ~500 color composite (C/Y/M) and ~500 black pages based on ISO/IEC 19798 and continuous printing. Replacement cartridge average composite (C/Y/M) declared yield ~1000 and average black yield ~1300 pages based on ISO/IEC 19798 and continuous printing. Actual yields vary considerably based on images printed and other factors. For details see hp.com/go/learnaboutsupplies. Imaging drum yield is ~14,000 pages when printing in black; ~7000 pages when printing in color; ~9000 to 10,000 pages when printing in average customer conditions. Pages may vary based on customer printing conditions and usage.

First page out (ready) black

As fast as 16 sec

First page out (ready) color

As fast as 27.5 sec

Resolution (black)

Up to 600 x 600 dpi quality (2400 dpi effective output with ImageREt 2400)

Resolution (color)

Up to 600 x 600 dpi quality (2400 dpi effective output with ImageREt 2400)

Resolution technology

HP ImageREt 2400

Monthly duty cycle

Up to 20,000 pages

Duty cycle is defined as the maximum number of pages per month of imaged output. This value provides a comparison of product robustness in relation to other HP LaserJet or HP Color LaserJet devices, and enables appropriate deployment of printers and MFPs to satisfy the demands of connected individuals or groups.

Recommended monthly page volume

250 to 950

HP recommends that the number of pages per month of imaged output be within the stated range for optimum device performance, based on factors including supplies replacement intervals and device life over an extended warranty period.

Print Technology

Laser

Display

3.0-in (7.62-cm) touchscreen CGD (Color Graphics Display)

Processor speed

600 MHz

Number of print cartridges

4 (1 each black, cyan, yellow, magenta), 1 imaging drum

Replacement cartridges

HP 130A Black LaserJet Toner Cartridge (~1300 yield) CF350A; HP 130A Cyan LaserJet Toner Cartridge (~1000 yield) CF351A; HP 130A Yellow LaserJet Toner Cartridge (~1000 yield) CF352A; HP 130A Magenta LaserJet Toner Cartridge (~1000 yield) CF353A; HP 126A LaserJet Imaging Drum CE314A

Print languages

PCLm/PCLmS

Automatic paper sensor

No

Paper trays, standard

1

Paper trays, maximum

1

ConnectivityBack to the top

Mobile printing capability

HP ePrint, Wireless direct printing, Apple AirPrint™

May require a firmware upgrade to be compatible, download at hp.com/go/support

HP ePrint capability

Yes

Connectivity, standard

Hi-Speed USB 2.0 port; built-in Fast Ethernet 10/100Base-TX network port; Wireless 802.11b/g/n

Network ready

Standard (built-in Fast Ethernet, WiFi 802.11 b/g/n)

Ports

1 Hi-Speed USB 2.0; 1 Fast Ethernet 10/100Base-TX; 1 Wireless 802.11b/g/n

Security

Password-protected network embedded Web server; 802.11: WEP, WPA, WPA2; SNMPv1 community password change

Minimum system requirements

Windows 8 (32/64-bit), Windows 7 (32/64-bit), Windows Vista (32/64-bit), Windows XP 32-bit (SP2 or higher); Minimum hard disk space required (CD and Web Package) 200MB; Minimum hard disk space required (Box Spec for Smart Install) 400MB; Minimum RAM installed 512MB CD-ROM/DVD or internet, USB or Network port

Mac OSX v 10.6; PowerPC G4, G5, or Intel® Core™ Processor; 500 MB available hard disk space; CD-ROM/DVD-ROM or Internet; USB or Network port

Compatible operating systems

Full software installs supported on: Windows 8 (32-bit/64-bit), Windows 7 (32-bit/64-bit), Windows Vista (32-bit/64-bit), Windows XP (32-bit) (SP2 or higher); Driver only installs supported on: Windows 2012; Windows Server 2008 (32-bit/64-bit), Windows Server 2008 R2 (x64) (SP1), Windows Server 2008 (Standard Edition), Windows Server 2008 (Enterprise Edition), Windows Server 2003 (32-bit/64-bit) (SP1 or higher), Windows XP (64-bit) (SP2 or higher); Mac OS X v 10.6.8 or higher; Linux: Please check Linux on-line support: hplipopensource.com/hplip-web/install.html

Memory specsBack to the top

Memory, standard

128 MB

Memory, maximum

128 MB

Printer management

Windows: HP Device Toolbox, Status Alerts (default install); Mac: HP Utility

Supported network protocols

Via built-in networking solution: TCP/IP, IPv4, IPv6; Print: LPD (raw queue support only); Discovery: SLP, Bonjour, Web Services Discovery; IP Config: IPv4 (BootP, DHCP, AutoIP, Manual), IPv6 (Stateless Link-Local and via Router, Statefull via DHCPv6); Management: SNMPv1, HTTP; HP ePrint

Hard disk

No

Paper handlingBack to the top

Paper handling input, standard

150-sheet input tray

Paper handling output, standard

50-sheet face-down bin

Duplex printing

Manual (driver support provided)

Envelope input capacity

Up to 10 envelopes

Finished output handling

Sheetfed

Media sizes supported

Letter, legal, executive, 4 x 6 in, 5 x 8 in, 8.5 x 13 in, envelopes (No. 10, Monarch)

Media sizes supported

A4; A5; A6; B5; 16k; 10 x 15 cm; post cards (JIS single and double); envelopes (DL, C5, B5)

Media sizes, custom

3 x 5 to 8.5 x 14 in

Media types

Paper (bond, brochure, colored, glossy, letterhead, photo, plain, preprinted, prepunched, recycled, rough), postcards, transparencies, labels, envelopes

Supported media weight

16 to 58 lb (bond)

Media weights by paper path

Cut sheet paper: 60 to 120 g/m² (Stretch Goal:-163g/m²); Envelopes: 60 to 90 g/m²; Post Cards: 135 to 176 g/m² (36 to 47 #); HP glossy media: 130 to 220 g/m²

Scanner specificationsBack to the top

Scanner type

Flatbed, ADF

Scan file format

Windows Scan Software supports file format: JPG, RAW (BMP), PDF, TIFF, PNG; Mac Scan Software supports file format: TIFF, PNG, JPEG, JPEG-2000, PDF, PDF Searchable, RTF, TXT

Scan resolution, hardware

Up to 1200 x 1200 dpi

Scan resolution, optical

Up to 1200 dpi

Scan size (flatbed), maximum

8.5 x 11.7 in

Scan size (ADF), maximum

8.5 x 14 in

Duplex ADF scanning

No

ADF Capacity

Standard, 35 sheets

Digital sending features

Scan to E-mail by HP Software; scan to application by HP Software; scan to file by HP Software

Digital send file Formats

PDF; TIF; BMP; PNG; JPG

Copier specificationsBack to the top

Copy speed black (normal)

Up to 17 cpm

Copy speed color (normal)

Up to 4 cpm

Copy resolution (black text)

Up to 300 x 300 dpi

Copy resolution (colour text and graphics)

Up to 300 x 300 dpi

Copy reduce / enlarge settings

25 to 400%

Copies, maximum

Up to 99 copies

Fax specsBack to the top

Faxing

Yes

Fax transmission speed

3 sec per page

Based on standard ITU-T test image #1 at standard resolution. More complicated pages or higher resolution will take longer and use more memory.

Fax memory

Up to 500 pages

Fax resolution

Up to 300 x 300 dpi

Speed dials, maximum number

Up to 100 numbers

Broadcast locations

100 locations

Power & operating requirementsBack to the top

Power

Input voltage: 110 to 127 VAC (+/- 10%), 60 Hz (+/- 2 Hz); Input Voltage: 220 to 240 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz) (Not dual voltage, power supply varies by part number with # Option code identifier).

Power consumption

290 watts (Printing), 200 watts (Copying), 9.2 watts (Ready), 1.3 watts (Sleep/Auto-Off), 0.2 watts (Manual Off)

Values subject to change. Power numbers are the highest values measured using all standard voltages. See hp.com/support for current information. Power requirements are based on the country/region where the printer is sold. Do not convert operating voltages. This will damage the printer and void the product warranty.

Energy efficiency

ENERGY STAR® qualified

Operating temperature range

50 to 86ºF

Operating humidity range

30 to 70% RH

Dimensions & weightBack to the top

Dimensions (W x D x H)

16.7 x 16.7 x 13 in

Maximum dimensions (W x D x H)

16.7 x 19 x 13 in

Weight

35 lb

Package weight

43.1 lb

What's includedBack to the top

What's in the box

HP LaserJet Pro Color MFP M177fw; Preinstalled introductory HP LaserJet Black, Cyan, Yellow, Magenta print cartridges (~500 pages); Installation guide; Getting Started guide; User's Guide; Support flyer; Warranty guide; Printer software and documentation on CD; Power cord; USB cable; Phone cord

Cable included

Yes, 1 USB

Warranty

1 year invoice warranty / 1 year card warranty (depending on selection)

Software included

Windows: HP Installer/Uninstaller, HP PCLmS print driver, HP WIA Scan Driver, HP TWAIN Scan Driver, HP Scan, HP Fax Setup Wizard, HP Send Fax, Status Alerts, HP Update, DXP; Mac: HP Installer/Uninstaller, HP PCLmS driver, HP Scan, HP Setup Assistant, HP Fax Print Driver, HP Utility, HP Alerts, HP Firmware Updater
