D-Link DCS‑7110 Outdoor Full HD Day & Night Fixed Bullet Network Camera

Buy D-Link DCS‑7110 Outdoor Full HD Day & Night Fixed Bullet Network Camera online at Rs. 28800 Buy complete range of CCTV Cameras on Vmart.pk, We Offer home delivery all over Pakistan.

The D-Link DCS-7110 is an all-in-one, outdoor network camera equipped with industry-leading high definition (Full HD) megapixel resolution and H.264 compression. The DCS-7110 connects to a network to provide high-quality live video over the Internet, capable of capturing video in both day and night environments thanks to its built-in IR LEDs and IR-cut removable (ICR) filter. This feature allows the camera to capture crisp colour images during the daytime and detailed grayscale images at night or in or low-light conditions.

The DCS-7110 supports simultaneous streaming of H.264, MPEG-4, and MJPEG video to provide both high-quality and bandwidth-efficient compression formats. H.264 produces a small file size, making it useful for extended recording in high detail or for use in low-bandwidth networks. MJPEG delivers excellent file integrity, ideal for situations which require better image quality. Additionally, the DCS- 7110 supports multicast H.264 streaming, allowing users to view the camera feed by subscribing to a multicast IP address on the network.

The DCS-7110 includes input and output ports for connectivity to external devices such as IR sensors, switches, and alarm relays. The DCS-7110 also incorporates Power over Ethernet (PoE), allowing it to be easily installed in a variety of locations without the need for supplemental power cabling.

Designed to be mounted outdoors, the DCS-7110 includes an IP66 certified enclosure which protects against the elements. Anti-tamper features make this camera suitable for tamper-prone locations such as transportation hubs, schools, or correctional facilities. The electronic tamper detection system can sense when the camera has been redirected, de-focused, blocked, or spray-painted, and respond promptly with a visible or audible alarm.

The included D-Link D-ViewCam™ is sophisticated software which allows users to manage up to 32 network cameras, set e-mail alert notifications, create recording schedules, and use motion detection to record directly to a hard drive. D-ViewCam™ also allows users to upload a floor plan to create a realistic layout of the premises where cameras are located, further simplifying the management process.

The D-Link DCS-7110 is an all-in-one, outdoor network camera equipped with industry-leading high definition (Full HD) megapixel resolution and H.264 compression. The DCS-7110 connects to a network to provide high-quality live video over the Internet, capable of capturing video in both day and night environments thanks to its built-in IR LEDs and IR-cut removable (ICR) filter. This feature allows the camera to capture crisp colour images during the daytime and detailed grayscale images at night or in or low-light conditions.

The DCS-7110 supports simultaneous streaming of H.264, MPEG-4, and MJPEG video to provide both high-quality and bandwidth-efficient compression formats. H.264 produces a small file size, making it useful for extended recording in high detail or for use in low-bandwidth networks. MJPEG delivers excellent file integrity, ideal for situations which require better image quality. Additionally, the DCS- 7110 supports multicast H.264 streaming, allowing users to view the camera feed by subscribing to a multicast IP address on the network.

The DCS-7110 includes input and output ports for connectivity to external devices such as IR sensors, switches, and alarm relays. The DCS-7110 also incorporates Power over Ethernet (PoE), allowing it to be easily installed in a variety of locations without the need for supplemental power cabling.

Designed to be mounted outdoors, the DCS-7110 includes an IP66 certified enclosure which protects against the elements. Anti-tamper features make this camera suitable for tamper-prone locations such as transportation hubs, schools, or correctional facilities. The electronic tamper detection system can sense when the camera has been redirected, de-focused, blocked, or spray-painted, and respond promptly with a visible or audible alarm.

The included D-Link D-ViewCam™ is sophisticated software which allows users to manage up to 32 network cameras, set e-mail alert notifications, create recording schedules, and use motion detection to record directly to a hard drive. D-ViewCam™ also allows users to upload a floor plan to create a realistic layout of the premises where cameras are located, further simplifying the management process.

• Superior Performance
• 1/2.7” 2 megapixel CMOS sensor
• Real-time H.264/ MPEG-4/ MJPEG
• Max. resolution of 1920x1080 at 15 fps
• Crystal Clear Feed
• Four (4) simultaneous streams
• Built-in 4 mm, F1.5 fixed lens
• 15M IR illumination distance
• IR-Cut Removable filter for day/night vision
• Robust Security
• Tamper detection
• Motion detection
• Privacy mask
• IPv6, 802.1x, QoS, CoS
• HTTPS secured streaming
• Full Compatibility
• Samba client
• IP66 weatherproof
• ONVIF compliant
• 12V DC, 24V AC and PoE
• DI/DO socket

• Hardware Profile
• 1/2.7” 2 Megapixel progressive CMOS sensor
• 15 metre IR illumination distance
• Built-in Infrared-Cut Removable (ICR) Filter module
• 4 mm fixed lens , F1.5
• Shutter speed: 1/5 - 1/32,000 seconds
• Angle of view:
  • 77.4° (H)
  • 45.1° (V)
  • 88° (D)
• Minimum object distance: 0.4 M
• Image Features
• Configurable image size, quality, frame rate, and bit rate
• Time stamp and text overlays
• 3 configurable motion detection windows
• Min Illumination:
• 0.12 Lux (day mode)
• 0 Lux (night mode) with IR LED
• 5 configurable privacy masks
• Flip & mirror
• Configurable white balance, shutter speed, brightness, saturation, contrast, sharpness

• Video Compression
• H.264/MPEG4/MJPEG format compression simultaneously
• JPEG for still image
• H.264/MPEG-4 multicast streaming
• Video Resolution
• 1920 x 1080 @ 15 fps
• 640x480 @ 30 fps
• 320x240 @ 30 fps
• 1280x800 @ 30 fps
• 1280x720 @ 30 fps
• Network Protocols
• IPv4
• IPv6
• TCP/IP
• UDP
• ICMP
• DHCP Client
• NTP Client (D-Link)
• DNS Client
• DDNS Client (D-Link)
• SMTP Client
• FTP Client
• HTTP / HTTPS
• Samba Client
• PPPoE
• UPnP Port Forwarding
• RTP/RTSP/RTCP
• IP filtering
• LLTD
• CoS/QoS
• SNMP
• IGMP
• 802.1x
• ONVIF Compliant
• Security
• Administrator and user group protection
• Password authentication
• HTTP and RTSP digest encryption
• HTTPS streaming
• System Requirements
• Microsoft Windows 2000, XP, Vista, 7
• Internet Explorer 7 or higher
• D-ViewCam™ System Requirements
• Operating System: Microsoft Windows ® 7/Vista/XP
• Web Browser: Internet Explorer 7 or higher
• Protocol: Standard TCP/IP
• Event Management
• Motion detection
• Event notification and upload snapshots/video clips via HTTP, SMTP or FTP
• Supports multiple HTTP, SMTP and FTP servers
• Multiple event notification
• Multiple recording methods for easy backup
• Surveillance Software Functions
• Remote management/control of up to 32 cameras
• Viewing of up to 32 cameras on one screen
• Supports all management functions provided in web interface
• Scheduled motion triggered and manual recording options
• External Device Interface
• DI and DO for external sensor and alarm

• Dimensions
• Ø66 x 172 mm
• Weight
• 808 grams (1.78 lbs)
• Power
• Input: 12 V DC 1.25 A, 24 V AC, 50/60 Hz, 802.3af PoE
• Max. Power Consumption
• 6.3W
• Temperature
• Operating temperature-20 to 50 ˚C (-4 to 122 ˚F)
• Storage:-20 to 70 ˚C (-4 to 158 ˚F)
• Humidity
• Operating: 0% to 90% non-condensing
• Certifications
• CE (Class A)
• CE LVD (EN60965-1)
• FCC (Class A)
• ICES-003
• C-Tick
