ASUS ROG Strix B450-E Gaming Motherboard

Buy ASUS ROG Strix B450-E Gaming Motherboard online at Low Price. Buy complete range of Motherboards on Vmart.pk, We Offer home delivery all over Pakistan.

ASUS ROG Strix B450-E Gaming AMD AM4 B450 ATX Gaming motherboard with DDR4 4400MHz support, 802.11ac Wi-Fi, SATA 6Gbps, HDMI 2.0, dual M.2, USB 3.1 Gen 2, and Aura Sync RGB LED lighting.

With ample power to fuel Ryzen's cores, plus cooling, storage and connectivity options for a range of hardware, the ROG Strix B450-E Gaming motherboard has everything you need to build on a budget or load up with high-performance components to game in the big leagues.

The ROG Strix B450-E Gaming uses new alloy chokes that deliver better efficiency, and high-quality thermal pads to help transfer heat from the VRM array to a sink that has ample surface area for the latest processors. And to ensure critical components always make optimal contact, there's a backplate on the rear of the board that helps balances MOSFET temperatures while providing structural reinforcement.

ROG Strix B450-E Gaming features the most comprehensive cooling options ever, configurable via Fan Xpert 4 or the UEFI BIOS.

A host of design touches, customization options, comprehensive validation lists, and the most diverse ecosystem of components in the industry make building and personalizing a gaming rig with ROG Strix B450-E Gaming wonderfully easy.

ROG Strix B450-E Gaming is equipped with two M.2 slots for maximum storage flexibility. With PCIe 3.0 x4 signals coming directly from the CPU, both slots are granted unrestricted bandwidth that maximize performance of your NVME SSDs. RAID configurations with up to three PCIe 3.0 storage devices are also possible via the two M.2 slots and a PCIe x16 slot, delivering incredible data-transfer speeds on the latest AMD platform.

AMD StoreMI technology is a software utility that accelerates any drive for better system responsiveness with reduced startup and software load times. It combines SSD performance with the affordability and capacity of an HDD by automatically moving frequently accessed data to dedicated SSD storage.

Tuned to take full advantage of Ryzen's capabilities, and ready for the latest memory kits, ROG Strix B450 Gaming Series motherboards are built specifically for high-performance gaming rigs. Intelligent firmware delivers the plug-and-play experience that first-time DIYers demand and the essential tuning options that performance-addicts need. Maximize frame rates with a high-bandwidth memory kit or leverage a host of tuning options to extract peak performance potential from a modest setup. Load up any way you want and get into the game with ROG Strix B450 Gaming Series motherboards.

ROG Strix B450-E Gaming features the latest Intel 802.11ac Wi-Fi with 2x2 MU-MIMO and wide 160MHz channels, for wireless speeds of up to 1.73Gbps.* In fact, its integrated Wireless-AC 9260 Wi-Fi adapter pushes wireless data up to 2X faster than other Wi-Fi solutions — so you'll get fast, smooth transfers, even when your rig is further away from the router. Intel Wireless-AC 9260 also offers Bluetooth 5.0 for connections that are up to 2X faster than ever before, and with up to 4X the range.

ROG Strix B450-E Gaming features Intel Ethernet (I211-V), ensuring data exchanges with your network and the outside world are fast and smooth. Intel LAN reduces CPU overhead and increases TCP and UDP throughput, keeping more processing power available for the game.

Featuring advanced signal-coupling technology and high-tolerance components, LANGuard provides consistent Ethernet performance and greater protection against static electricity and power surges.

ROG Strix's SupremeFX audio technology has levelled up, delivering an exceptional 113dB signal-to-noise ratio on the line-in connection for best-ever recording quality — and 120dB on line-out for crystal-clear sound! We've also added a low-dropout regulator for cleaner power delivery to the SupremeFX S1220A codec, plus Texas Instruments® RC4580 and OPA1688 op-amps for high gain with low distortion. It all adds up to audio that envelops you as never before!

The ASUS Aura ecosystem is in the ascendancy, with an extensive and growing list of ASUS products now offering Aura Sync compatibility — along with loads of compatible accessories and kits available through partners. Your ROG Strix motherboard's built-in Aura RGB lighting easily syncs with PC cases, memory modules, coolers and RGB LED strips from a broad selection of well-known manufacturers. ASUS Aura software provides simple and intuitive lighting management.

The AMD Ryzen™ processor is based on the innovative Zen core architecture and features up to eight cores and Radeon™ Vega integrated graphics. Together with dual-channel DDR4 memory, native 5Gbps USB 3.1 Gen 1 and 16 PCI Express® 3.0/2.0 lanes, these AMD AM4-socket processors deliver superb computing performance.

The AMD B450 chipset delivers high performance and flexibility with the latest AMD® AM4-socket Ryzen™ processors. It also offers AMD StoreMI storage acceleration technology and provides two 10Gbps USB 3.1 Gen2 ports, two USB 3.1 Gen1 ports, and four 6Gbps SATA ports for faster data retrieval.

AMD AM4 Socket AMD Ryzen™ 2nd Generation/Ryzen™ with Radeon™ Vega Graphics/Athlon™ with Radeon™ Vega Graphics/Ryzen™ 1st Generation Processors.

AMD B450

Memory

AMD Ryzen™ Processors

4 x DIMM, Max. 64GB, DDR4 3533(O.C)/3466(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory

Dual Channel Memory Architecture

Integrated Graphics in the AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors

Multi-VGA output support : HDMI/DisplayPort ports

- Supports HDMI 2.0b with maximum resolution of 4096 x 2160 @ 60 Hz

- Supports DisplayPort 1.2 with max. resolution 4096 x 2160 @ 60 Hz

Supports AMD 3-Way CrossFireX™ Technology

2 x PCIe 3.0/2.0 x16 (x16 or x8/x4)

1 x PCIe 3.0/2.0 x16 (x8 mode)

1 x PCIe 3.0/2.0 x16 (x8 mode) *1

1 x PCIe 2.0 x16 (max at x4 mode)

3 x PCIe 2.0 x1

1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*3

1 x M.2 Socket 3, , with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)*4

2 x SATA 6Gb/s port(s)

1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*3

2 x SATA 6Gb/s port(s)

1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA mode)

4 x SATA 6Gb/s port(s),

Support Raid 0, 1, 10

Intel® I211-AT, 1 x Gigabit LAN Controller(s)

Anti-surge LANGuard

ROG GameFirst Technology

Intel® Wireless-AC 9260

Supports dual band frequency 2.4/5 GHz

Supports 2x2 MU-MIMO

Bluetooth 5.0

ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A

- Dual OP Amplifiers

- Impedance sense for front and rear headphone outputs

- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking

- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input

- SupremeFX Shielding Technology

- Supports up to 32-Bit/192kHz playback

- Optical S/PDIF out port(s) at back panel

- Sonic Radar III

- Sonic Studio III + Sonic Studio Link

3 x USB 3.1 Gen 1 port(s) (3 at back panel, blue)

1 x USB 3.1 Gen 1 port(s) (1 at back panel, , Type-C)

2 x USB 3.1 Gen 2 port(s) (2 at back panel, red)

2 x USB 3.1 Gen 1 port(s)

4 x USB 2.0 port(s) (2 at back panel, , 2 at mid-board)

ROG CPU-Z

Pre-mounted I/O Shield

Overwolf

GameFirst IV

ROG Exclusive Software

- RAMCache III

- GameFirst V

- Whole system optimization with a single click! 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Xpert 4, and Turbo App together, providing better CPU performance, efficient power saving, precise digital power control, whole system cooling and even tailor your own app usages.

- Auto Tuning, TurboV, GPU Boost

- Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors selection for optimized system cooling control

- ESD Guards on LAN, Audio, KBMS and USB3.1/3.0/2.0 ports

- DRAM Overcurrent Protection

- Highly Durable Components

- SafeSlot

- EPU

- Aura Lighting Control

- Aura RGB Strip Headers

- Aura Lighting Effects Synchronization with compatible ASUS ROG devices

- AI Suite 3

- Ai Charger

- Armoury Crate

- ASUS CrashFree BIOS 3

- ASUS EZ Flash 3

- ASUS Q-Shield

- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)

- ASUS Q-Slot

- ASUS Q-DIMM

- featuring system performance tuning for selected applications

1 x PS/2 keyboard/mouse combo port(s)

1 x DisplayPort

1 x HDMI

1 x LAN (RJ45) port(s)

2 x USB 3.1 Gen 2 (red)Type-A,

4 x USB 3.1 Gen 1 (blue)

2 x USB 2.0

1 x Optical S/PDIF out

5 x Audio jack(s)

1 x Addressable RGB header

2 x Aura RGB Strip Headers

1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)

1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)

1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)

1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)

1 x TPM header

1 x COM port(s) connector(s)

6 x SATA 6Gb/s connector(s)

1 x CPU Fan connector(s)

1 x CPU OPT Fan connector(s)

3 x Chassis Fan connector(s)

1 x AIO_PUMP connector

1 x 24-pin EATX Power connector(s)

1 x 8-pin EATX 12V Power connectors

1 x Front panel audio connector(s) (AAFP)

1 x System panel(s)

1 x Thermal sensor connector(s)

1 x Clear CMOS jumper(s)

Windows® 10 64-bit

Windows® 7 64-bit

ATX Form Factor

12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )

PCIe x16_3 slot shares bandwidth with PCIe x1_2 and PCIe x1_3.

Support StoreMI and NVMe RAID

When the M.2_1 Socket 3 is operating in SATA or PCIE mode, SATA6G_5/6 ports will be disabled.

When the M.2_2 is occupied by M.2 device, PCIe x16_1 will run at x8 mode.

Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.

Windows 7 64-bit is only supported when using AMD Ryzen™ 2nd Generation/ Ryzen™ 1st Generation Processors
