D-Link DES-1008A 8-Port 10/100 Switch

The DES-1008A 8-Port 10/100 Switch is is an 8-port 10/100 Mbps Fast Ethernet switch that allows you to quickly set up a wired network. Connect the DES-1008A to multiple computers together to share files and folders, or connect it to a router to share an Internet connection.

The D-Link DES-1008A 8-Port 10/100 Switch uses auto-sensing 10/100 Mbps ports, allowing a small workgroup to flexibly connect to Ethernet and Fast Ethernet devices to create an integrated network. These ports detect the network speed and auto-negotiate between 10BASE-T and 100BASE-TX, as well as between full and half-duplex, allowing you to get the maximum speed possible for each device connected to your network.

All ports support automatic MDI/MDIX crossover, eliminating the need for crossover cables or uplink ports. Each port can be plugged directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables.

802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full. This gives you a more reliable connection for all of your connected devices, ensuring smooth and uninterrupted network connection.

Key Features

• Inexpensive Fast Ethernet solution for
• Home/SOHO
• 8 10/100 Mbps Fast Ethernet ports
• Auto MDI/MDIX crossover for all ports
• Store-and-forward switching scheme
• Full/half-duplex for Ethernet/Fast
• Ethernet speeds
• IEEE 802.3x Flow Control
• Plug-and-play installation
• RoHS compliant

SWITCHING FABRIC

• 1.6 Gbps switching fabric

Standards

• IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x flow control

Protocol

• CSMA/CD

Data Transfer Rates

• Ethernet:
• 10 Mbps (half duplex)
• 20 Mbps (full duplex)
• Fast Ethernet:
• 100 Mbps (half duplex)
• 200 Mbps (full duplex)

Topology

• Star

Media Interfa ce Exchange

• Auto MDI/MDIX adjustment for all ports

Network Cables

• 10BASE-T:
• UTP CAT 3/4/5/5e (100 m max.)
• EIA/TIA-586 100-ohm STP (100 m max.)
• 100BASE-TX
• UTP CAT 5/5e (100 m max.)
• EIA/TIA-568 100-ohm STP (100 m max.)

LED Indicators

• Per port:
• Link/Activity
• Per device:
• Power

Transmission Method

• Store-and-forward

MAC Address Tab le

• 1K entries per device

MAC Address Learning

• Automatic update

Packet Filtering/Forwarding Rates

• Ethernet: 14,880 pps per port
• Fast Ethernet: 148,800 pps per port

RAM Buffer

• 57 KBytes per device

DC Input

• External 5V/1A power adapter

Power Consumption

• Power On (Standby):
• DC input: 0.5 watts
• AC input: 1.4 watts
• Maximum:
• DC input: 3.25 watts
• AC input: 4.23 watts

Heat Dissipa tion

• Power On (Standby):
• AC input: 4.77 BTU/h
• Maximum:
• AC input: 14.42 BTU/h

Operating Temperature

• 0 to 40 ?C (32 to 104 ?F)

STORAGE TEMPERATURE

• -10 to 70 ?C (14 to 158 ?F)

OPERATING HUMIDITY

• 10% to 90% RH non-condensing

Storage Humidity

• 5% to 90% RH non-condensing

Device Dimensions (W x D x H)

• 128 x 68.5 x 25.4 mm (5.0 x 2.7 x 1.0 inches)

Certifications

• FCC Class B
• CE Class B
• CB
